Custom Copper Nickel Pipe Fittings C70600 90/10 Elbow Tee Reducer Flange

  • Custom Copper Nickel Pipe Fittings C70600 90/10 Elbow Tee Reducer Flange
  • Custom Copper Nickel Pipe Fittings C70600 90/10 Elbow Tee Reducer Flange
  • Custom Copper Nickel Pipe Fittings C70600 90/10 Elbow Tee Reducer Flange
Τόπος καταγωγής Σαγκάη, Κίνα
Μάρκα TOBO
Πιστοποίηση ISQ/TUV/SGS
Αριθμό μοντέλου Αγκώνας χαλκού νικελίου
Ποσότητα παραγγελίας min 1 τεμ
Τιμή Διαπραγματεύσιμα
Συσκευασία λεπτομέρειες Τυπικό πακέτο αποστολής
Χρόνος παράδοσης 15-30 εργάσιμες ημέρες
Όροι πληρωμής T/T, Western Union
Δυνατότητα προσφοράς 10 Δέκα/Μήνα
Λεπτομέρειες
Όνομα προϊόντος Αγκώνας χαλκού νικελίου Εκτίμηση θερμοκρασίας -196°C έως 300°C
Δύναμη Ψηλά Εκτίμηση πίεσης 150 - 3000 PSI
Πρότυπο ASMEB16.5 Sizerange 1/2 ίντσα έως 24 ίντσες
Φινίρισμα Επιφανείας Σκορπιλοποιημένο, άμμο, παθητικοποίηση Γωνία 45 μοίρες ή 90 μοίρες
Επισημαίνω

Custom Copper Nickel Pipe Fittings

,

C70600 Copper Nickel Elbow

,

90/10 Copper Nickel Flange
Αφήστε ένα μήνυμα
Περιγραφή προϊόντων

Custom Copper Nickel Pipe Fittings C70600 90/10 Elbow Tee Reducer Flange

Product Description

Our Custom Copper Nickel C70600 (90/10) Pipe Fittings are precision-engineered for demanding marine, offshore, and industrial seawater applications. Manufactured from high-grade UNS C70600 alloy—the industry standard for seawater piping—these fittings deliver an optimal balance of corrosion resistance, mechanical strength, and long-term reliability.

Available in Elbows (45°/90°/180°), Tees, Reducers, Flanges, Caps, and Stub Ends, our fittings comply with ASTM B466, ASME B16.9, EEMUA 144, and DIN 86019. We support Butt Weld, Socket Weld, and Threaded connections, sizes from 1/2" to 24" NB, and schedules Sch 5S to XXS. Full customization—special angles, tolerances, markings, and machining—is available with 100% material traceability.

2. ⚙️ Key Technical Parameters



Property C70600 Specification
Composition Cu (≥88.6%), Ni 9.0–11.0%, Fe 1.0–1.8%, Mn 0.5–1.0%
Tensile Strength 290–345 MPa (min 38–50 ksi)
Yield Strength 105–135 MPa (min 13–40 ksi)
Elongation 30–45%
Hardness 60–90 HRB
Density 8.94 g/cm³
Size Range 1/2" – 24" NB (DN15 – DN600)
Schedule Sch 5S, 10S, 40S, 80S, 160S, XXS

3. 🔥 Why Choose C70600 90/10?

⚓ Unmatched Corrosion Resistance – Forms a protective oxide film providing outstanding resistance to general corrosion, pitting, and crevice attack. Long-term corrosion rates stabilize below 2.5 µm/year in seawater, with excellent erosion resistance at flow velocities up to 3.0–3.5 m/s.

🛡️ Superior Biofouling Resistance – Continuous release of cuprous ions retards marine organism settlement. This natural self-cleaning characteristic eliminates costly cleaning procedures and reduces chlorine treatment requirements.

🔥 Wide Temperature Range – Maintains structural integrity up to 260°C while retaining ductility and impact strength even at cryogenic temperatures (-196°C) —ideal for heat exchangers, condensers, and evaporators.

🛠️ Excellent Weldability – Single-phase FCC structure ensures no phase transformation during welding. Compatible with TIG, MIG, and oxyacetylene welding with no post-weld heat treatment required.

📋 Full Traceability – Every fitting includes MTC 3.1, heat number traceability, and marine classification certificates (DNV-GL, ABS, Lloyd's Register) upon request.

4. 🏭 Primary Applications



Sector Applications
Marine & Shipbuilding Seawater piping, ballast systems, firewater, cooling
Desalination Intake/outlet lines, evaporator tubes
Offshore Platforms Hydraulic lines, seawater risers
Power Generation Condenser tubes, heat exchangers

5. 📦 Packaging, Payment & Delivery

Packaging: VCI paper wrapping + plastic end caps + seaworthy wooden crates
Payment: T/T (30% deposit + 70% balance) or L/C at sight
Lead Time: 25–30 days (standard); 7–15 days (samples)
MOQ: 1 piece
Shipping: FOB/CIF/EXW/CFR with full insurance and tracking

6. 🔧 Installation & After-Sales

Installation: Clean surfaces before installation; TIG/MIG welding recommended; no post-weld heat treatment needed. Avoid direct contact with carbon steel in wet environments.

Storage: Keep in clean, dry, well-ventilated areas; protect threads and ends during transport.

After-Sales: Full replacement for non-conforming material upon verified inspection. Returns accepted within 15 days for quality-related issues. Lifetime technical consultation available.

📞 Contact Us Today

Whether you need standard stock or fully customized fittings, our team is ready to support your project with competitive pricing, reliable quality, and on-time delivery.

Request your quote now! Provide your specifications and we will respond within 24 hours.



Custom Copper Nickel Pipe Fittings C70600 90/10 Elbow Tee Reducer Flange 0

Ετικέττες:

90Deg συναρμολογήσεις συγκόλλησης άκρης

Αγκώνας νικελίου χαλκού EEMUA 146

C70600 αγκώνας νικελίου χαλκού
